RAPID Patella Luxation
Patella Correction - Safe and Simple
Building upon the principles of TTT (Tibial Tuberosity Transposition), the RAPID Luxation Plating System offers enhanced accuracy, stability, and ease of use.
With its cleverly designed implants and specialized instrumentation, the RAPID Luxation Plating System enables a safe and precise transposition of the tibial tuberosity to correct a patella luxation.
RAPID PATELLA LUXATION SYSTEM
RAPID Patella Luxation - See all products
Sort by:
Contains:
Sterilization Tray with Lid
3 of each 2.0mm Screw (6-20mm, 24 pcs. total)
3 of each 2.4mm Screw (6-40mm, 54 pcs. total)
1 of each Rapid Luxation Plate (3 pcs. total)
1 of each Patella Spacer (18 pcs. total)
Large Sawguide with Pin & K-Wire
Petite Sawguide with Pin & K-Wire
Tibia Tappet Petite
Tibia Tappet Standard
Screwdriver Handle
Screw Driver Shaft 2.4/2.0 or T8
Holding Sleeve (Hexagonal Set only)
Plate Holding Forceps
Depth Gauge
Drill Guide
Drills 1.5 + 1.8
| Version | Thickness |
Screw Size (with gliding holes) | SKU |
| 6-hole | 1.5 mm | 2.4 mm | 132-8200-01 |
| 4-hole | 1.0 mm | 2.4 mm | 132-8200-02 |
| 4-hole (petite) | 1.0 mm | 2.0 mm | 132-8200-03 |
2.0 diameter Cortical Screw, Titanium, Non-Locking, with LeiStar head, self tapping, with three flute cutting edge
2.4 mm Cortical Screw, Titanium, Non-Locking, with Hexagonal head, self-holding, self-tapping with three flute cutting edge
For inserting Patella Luxation Spacers
Petite/Tiny Version: For Petite/Tiny TTA RAPID® Cages and Patella Luxation Plates (132-8200-03)
Standard Version: For Standard TTA RAPID® Cages and Patella Luxation Plates (132-8200-01/132-8200-02) Caution: It does not fit onto petite Cages!
L-shaped Saw Guide, Stainless Steel
| Product Code | Description |
| 132-4042-00 | For TTA RAPID® Tiny cages 2 - 6 mm and RAPID Luxation Petite Plate 132-8200-03 |
| 132-4041-00 | For TTA RAPID® Standard cage sizes 3 - 4.5 mm and RAPID Luxation Plates 132-8200-02 & -03 |
| 132-4040-00 | For TTA RAPID® Standard cage sizes 6 - 15 mm and RAPID Luxation Plates 132-8200-01 & -02 |
150 mm in length
| Product Code | Description | Compatibility |
| 164-1013-20 | Scale up to 20 mm | for 1.0/1.3/1.5mm screws |
| 164-1520-20 | Scale up to 40 mm | for 1.5/2.0/2.4mm screws |
| 064-2735-60 | Scale up to 60 mm | for 2.4/2.7/3.5mm screws |
With standard sawblade, incl. Allen Wrench 1.5mm
